SAMOTO IHS5500 - HYBRID SOLAR INVERTER 5500VA WITH LCD INTERFACE

Detail Produk

INPUT
Model : IHS5500
Capacity (VA) : 5500VA
Input Standard : L+N+PE
Rated Input Voltage : 220/230/240VAC
Voltage Range : 90-280VAC±3V (APL Mode)170-280VAC±3V (UPS Mode)
Frequency Range : 50/60Hz (Auto Adaptive)

OUTPUT
Rated Power Battery Invers : 5500W
Rated Power Photovolatic Inverter : 6500W
Output Voltage : 220/230/240VAC±5%
Output Frequency : 50/60Hz±0.1%
Output Wave : Pure Sine Wave
Transfer Time (adjustable) : Computers (UPS Mode) 10Mns, Appliance (APL Mode) 20Mns
Peak Power : 11000Va
Overload Ability : Battery mode 11s@105%~150%Load; 2s@150%~200% Load; 400Ms@>200% Load
GRID-CONNECTED OPERATION
Output Voltage : 220/230/240VAC±5%
Fead Into The Grid Voltage Range : 195-253VA
Fead Into The Grid Frequency Range : 49-51±1Hz/59-61±1Hz
Nominal Output Current : 23.9A
Power Factor Range : >0.99
Max. Conversion Efficiency (DC?AC) : 0.98%

BATTERY
Battery Voltage : 48VDC
Constant Charging Voltage (adjustable) : 56.4VDC
Floate Charging Voltage (adjustable) : 54VDC

CHARGER
PV Charging Method : MPPT
Max. PV Input Power : 7500W
MPPT Tracking Range : 60-500VDC
Best Voltage : 300~400VDC
Max. PV Input Voltage : 500VDC
Max. PV Input Current : 27A
Max. PV Charging Current : 100A
Max. AC Charging Current : 100A
Max. Charging Current : 100A
DISPAY
LCD Interface : Can display running mode/load/input/output,etc

COMMUNICATION PORT
RS232 : Baud Rate 2400
Extend The Socket Communication Interface : Lithium Battery BMS Communication Card, Wifi Card,Dry Contact
Parallel Machine Interface : Parallel Machine (network) Function

ENVIROMENTAL PARAMETER
Operating Temperature : -10°C~50°C
Humidity : 20%-95% (no condensing)
Storage Temperature : -15~60°C
Altitude : Altitude not over 100om, derating over 1000m, max. 4000m refer to IEC62040
Noise : ≤50db

PHYSICAL PARAMETER
Size L*W*H (mm) : 490*310*120mm
Weight Product /+box (kg) : 10.36 Kg/11.92Kg
